Mechanical information
 Side view of the Emulation adapter complete setup - QFP Fixed Adaptation
|
|
 Top view of the Emulation Adapter
|
 Top view of the Conversion board
|
Ordering code |
Unit (mm) |
||||||
|---|---|---|---|---|---|---|---|
M |
N |
P |
R |
S |
T |
V |
|
IEA.S32K344 |
70 |
70 |
|
|
32.6 |
36.4 |
47.5 |
IEA-S32K344-xxxxx |
|
|
70 |
70 |
|
|
|
QFP
 Solder part Solder pad view
|
 Top view of the Solder part
|
In the case of soldering the Solder part manually, it’s highly recommended to prolong the solder pad E on the outer side (e.g., for 1.5–2 mm) during the PCB design. Note that without this modification, it’s very difficult to solder the Solder part manually.
Recommended PCB footprint dimensions:
Ordering code |
Unit (mm) |
||||||
|---|---|---|---|---|---|---|---|
A |
B |
C |
D |
E |
K |
L |
|
IA48TQ-SOLDER |
9 |
1.005 |
10 |
10 |
1.75 |
12 |
12 |
HDQFP
|
For recommended HDQFP PCB footprint dimensions, follow the link: NXP HDQFP100 or NXP HDQFP172. |
Extenders
 Side view of the Extender
|
 Top view of the Extender
|
Ordering code |
Unit (mm) |
|
|---|---|---|
W |
Z |
|
IA100MQFP-EXTENDER |
22 |
3.25 |
IA172MQFP-EXTENDER |
16 |
3.25 |
|
To view Emulation Adapter schematics, refer to Schematics . |
